2080-LC20-20QWB Allen Bradley MicroLogix 1000 Programmable Controllers

INQUIRE NOW

Products Name: 2080-LC20-20QWB Allen Bradley MicroLogix 1000 Programmable Controllers

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number: 2080-LC20-20QWB

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:1.5kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

System Mounting Requirements

There are several things that you need to take into account when

preparing to mount the Ultra3000:

• The Ultra3000 must be enclosed in a grounded conductive

enclosure offering protection as defined in standard EN 60529

(IEC 529) to IP22 such that they are not accessible to an operator

or unskilled person, in order to comply with UL® and CE

requirements. A NEMA 4X enclosure exceeds these requirements

providing protection to IP66.

• The ambient temperature of the location in which you will install

the Ultra3000 must not exceed 55° C (131° F).

• You must install the Ultra3000 vertically on the panel (refer to

Figure 1.4 for mounting orientation).

• You must install the panel on a flat, rigid, vertical surface that

won’t be subjected to shock, vibration, moisture, oil mist, dust, or

corrosive vapors.

• You need to maintain minimum clearances (refer to Figure 1.4) for

proper airflow, easy module access, and proper cable bend radius.

• The Ultra3000 can operate at elevations to 1000 m (3280 ft)

without derating, however, the continuous current rating must be

de-rated by 3% for each additional 300 m (984 ft) up to 3000 m

(9842 ft). Consult your local Allen-Bradley representative prior to

operating above 3000 m (9842 ft).

Refer to Appendix A for mounting dimensions, power dissipation, and

environmental specifications for the Ultra3000.

Plan the installation of your system so that you can

perform all cutting, drilling, tapping, and welding

with the system removed from the enclosure.

Because the system is of the open type construction,

be careful to keep any metal debris from falling into

it. Metal debris or other foreign matter can become

lodged in the circuitry, which can result in damage to

components.

Transformer Sizing

The Ultra3000 does not require isolation transformers. However, a

transformer may be required to match the voltage requirements of the

controller to the available service. To size a transformer for the main

AC power inputs, the power output (KVA) of each axis must be

known. This can be derived by calculating the horsepower for each

axis and converting that horsepower into units of watts. If you are

supplying power to more than one motor and an Ultra3000, simply

add the kW ratings together from each calculation to get a system kW

total.

2080-LC20-20QWB  Allen Bradley    MicroLogix 1000 Programmable Controllers

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
