2090-XXLF-375B Allen-Bradley

For general guidelines when laying out your panel and mounting your ac line filter,

refer to the System Design for Control of Electrical Noise Reference Manual,

publication GMC-RM001. For guidelines specific to your application, refer to

Additional Resources on page 11 for the user manual available for your servo drive.

Description:

To avoid personal injury or damage to equipment due to hazardous voltages,

follow these guidelines when installing your ac line filter. NEC and local

regulations always take precedence.

• Disconnect mains power prior to installation.

• Verify that the rated voltage is compatible with the local supply voltage.

• Connect the earth ground connection first when making connections.

IMPORTANT Remove corrosion, oil, or grease from bus bar mountings by scrubbing surfaces

with a dry scrubbing pad. Do not touch cleaned surfaces with bare hands to

prevent further contamination.

TIP The Bulletin 2094 mounting brackets, catalog number 2094-XNBRKT-1, are

designed to save panel space by letting you mount the Kinetix 6000 power rail

or line interface module (LIM) over the ac line filter.

Refer to the 2094 Mounting Brackets Installation Instructions, publication

2094-IN008, for more information.
