2098-DSD-075-SE Allen Bradley MicroLogix 1000 Programmable Controllers

INQUIRE NOW

Products Name: 2098-DSD-075-SE Allen Bradley MicroLogix 1000 Programmable Controllers

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:2098-DSD-075-SE

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.51kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Observe the following safety precautions when troubleshooting your

Ultra3000 drive.

DC bus capacitors may retain hazardous voltages

after input power has been removed. Before

working on the drive, measure the DC bus voltage to

verify it has reached a safe level or wait the full time

interval listed on the drive warning label. Failure to

observe this precaution could result in severe bodily

injury or loss of life.

Do not attempt to defeat or override the drive fault

circuits. You must determine the cause of a fault and

correct it before you attempt to operate the system. If

you do not correct a drive or system malfunction, it

could result in personal injury and/or damage to the

equipment as a result of uncontrolled machine

system operation.

Test equipment (such as an oscilloscope or chart

recorder) must be properly grounded. Failure to

include an earth ground connection could result in a

potentially fatal voltage on the oscilloscope chassis.

This section provides information to assist you in wiring the Ultra3000

CN1 (44-pin) cable connector with either the ControlLogix

1756-M02AE servo module or SoftLogix™ 1784-PM02AE motion card.

Use the 2090-U3AE-D44xx control interface cable (shown below)

when connecting two Ultra3000 drives to the 1756-M02AE servo

module. This cable includes the 1756-TBCH pre-wired terminal block.

Refer to Figure B.22 for the interconnect diagram.

1761-CBl-AP00 Allen Bradley    MicroLogix 1000 Programmable Controllers

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
