2098-DSD-HV100X Allen Bradley Ultra3000 Digital Servo Drives

INQUIRE NOW

Products Name: 2098-DSD-HV100X Allen Bradley Ultra3000 Digital Servo Drives

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number: 2098-DSD-HV100X

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:1.38kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Product Receiving and

Storage Responsibility

You, the customer, are responsible for thoroughly inspecting the

equipment before accepting the shipment from the freight company.

Check the item(s) you receive against your purchase order. If any

items are obviously damaged, it is your responsibility to refuse

delivery until the freight agent has noted the damage on the freight

bill. Should you discover any concealed damage during unpacking,

you are responsible for notifying the freight agent. Leave the shipping

container intact and request that the freight agent make a visual

inspection of the equipment.

Store the product in its shipping container prior to installation. If you

are not going to use the equipment for a period of time, store using

the following guidelines.

• Use a clean, dry location

• Maintain an ambient temperature range of -40 to 70° C

(-40 to 158° F)

• Maintain a relative humidity range of 5% to 95%, non-condensing

• Store it where it cannot be exposed to a corrosive atmosphere

• Store it in a non-construction area

Meeting CE Requirements

To meet CE requirements the following components are required:

• Install an AC line filter (2090-UXLF-xxx or -HVxxx) between the

AC power source and the drive input, and as close to the drive as

possible (refer to Appendix C for available AC line filters). The

supply must be grounded for the filter to operate properly.

• Connect auxiliary input power (if required) from the load side of

the AC line filter to the drive.

• Use 2090 series motor power and feedback cables and terminate

the motor power cable shields to the chassis clamp provided

(refer to Chapter 3 for wiring instructions).

• When installing the Ultra3000 system inside an enclosure, run

input power wiring (grounded to the enclosure) in conduit

outside of the enclosure.

• Separate signal and power cables as shown in Planning Your

Panel Layout of this chapter.

Low Voltage Directive

These units are tested to meet Council Directive 73/23/EEC Low

Voltage Directive. The EN 60204-1 Safety of Machinery-Electrical

Equipment of Machines, Part 1-Specification for General Requirements

standard applies in whole or in part. Additionally, the standard

EN 50178 Electronic Equipment for use in Power Installations applies

in whole or in part.

Refer to Appendix B for interconnect information.
