2198-D012-ERS4 Allen Bradley Guard Locking Switch

INQUIRE NOW

Products Name: 2198-D012-ERS4 Allen Bradley Guard Locking Switch

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:2198-D012-ERS4

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.3kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

IMPORTANT For effective cooling, mount the module following these guidelines.

• Mount the module horizontally.

• Provide a gap of at least 100 mm (3.94 in.) above and below the module.

• Select a location where air flows freely or use an additional fan.

• Do not mount the module over a heating device.

The module cannot be panel-mounted. Mount the module to a DIN rail by following the steps

below.

1. Hook the top slot over the DIN rail.

2. Insert a flathead screwdriver into the gap

between the housing and the latch and pull

the latch downward.

3. Hold the latch down as you push the housing

back onto the DIN rail.

4. Release the latch to lock the module onto the

rail.

Ground the Module

The module is functionally grounded through its DIN rail connection. A protective earth

ground connection is required and is provided through a separate grounding screw on the upper

left of the housing and marked with the grounding symbol .

You must also provide an acceptable grounding path for each device in your application. For

more information on proper grounding guidelines, refer to the Industrial Automation Wiring

and Grounding Guidelines, publication 1770-4.1.

IMPORTANT For effective cooling, mount the module following these guidelines.

• Mount the module horizontally.

• Provide a gap of at least 100 mm (3.94 in.) above and below the module.

• Select a location where air flows freely or use an additional fan.

• Do not mount the module over a heating device.

TIP To remove the module from the DIN rail, insert a flathead screwdriver into

the gap between the housing and the latch and pull the latch downward as

you lift the module off of the rail.

ATTENTION: This product is grounded through the DIN rail to chassis ground.

Use zinc-plated yellow-chromate steel DIN rail to assure proper grounding. The

use of other DIN rail materials (for example, aluminum or plastic) that can

corrode, oxidize, or are poor conductors, can result in improper or intermittent

grounding. Secure DIN rail to mounting surface approximately every 200 mm

(7.8 in.) and use end-anchors appropriately

2198-D012-ERS4   Allen Bradley   Guard Locking Switch
