2198-H070-P Allen Bradley MicroLogix 1000 Programmable Controllers

INQUIRE NOW

Products Name: 2198-H070-P Allen Bradley MicroLogix 1000 Programmable Controllers

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number: 2198-H070-P

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.21kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

External Power Switch

The 1769-OF2 (Series B or later) has an external 24V dc power switch

which gives you the option of using an external power supply. The switch

is located in on the lower left portion of the module’s circuit board, as

shown below. With this switch in the up position (default), 24V dc power

is drawn from the 1769 system power supply via the 1769 I/O bus. In the

down position, 24V dc power is drawn from the external power supply.

Wire the external power supply to the module via the module’s terminal

block. The external power supply must be rated Class 2, with a 24V dc

range of 20.4 to 26.4V dc and 120 mA minimum.

Wiring Output Devices

Basic wiring of output devices is shown below.

!

ATTENTION • Miswiring of the module to an AC/DC source will

damage the module.

• Be careful when stripping wires. Wire fragments that

fall into a module could cause damage at power up.

Once wiring is complete, ensure the module is free of

all metal fragments.

Wiring the Finger-Safe Terminal Block

When wiring the terminal block, keep the finger-safe cover in place.

1. Loosen the terminal screws to be wired.

2. Route the wire under the terminal pressure plate. You can use the bare

wire or a spade lug. The terminals will accept a 6.35 mm (0.25 in.) spade

lug.

3. Tighten the terminal screw making sure the pressure plate secures the

wire. Recommended torque when tightening terminal screws is 0.68 Nm

(6 in-lbs).

NOTE The terminal screws are non-captive. Therefore, it is

possible to use a ring lug [maximum 1/4 inch o.d. with a

0.139 inch minimum i.d. (M3.5)] with the module.

NOTE If you need to remove the finger-safe cover, insert a screw

driver into one of the square, wiring holes and gently pry

the cover off. If you wire the terminal block with the

finger-safe cover removed, you will not be able to put it

back on the terminal block because the wires will be in the

way

2198-H070-P Allen Bradley    MicroLogix 1000 Programmable Controllers
