5069-AENTR Allen-Bradley

• Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous.

• Earthing is accomplished through mounting of modules on rail.

• Devices shall be used in an environment of not more than Pollution Degree 2.

• The equipment must be used only with ATEX/IECEx certified Rockwell Automation backplanes.

The Compact 5000™ I/O EtherNet/IP adapters perform the following functions:

• Facilitate high-speed data transfer across an EtherNet/IP network between Compact 5000 I/O modules and a Logix 5000™ controller.

• Provide system-side and field-side power to Compact 5000 I/O modules.

• Support as many as 31 Compact 5000 I/O modules

The adapters are configured with the Studio 5000 Logix Designer® application. For more information on how to use Compact 5000 I/O

EtherNet/IP adapters, including the compatible Logix 5000 controllers and Logix Designer application versions.

The publication has been changed as follows:

• Add Waste Electrical and Electronic Equipment (WEEE) information

• Add information about how to install an end cap

• Update the SA power and SA power Passthrough specification for the 5069-AENTR, and 5069-AENTRK adapters

The following applies to products with IECEx certification: Such modules:

• Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and for short

periods. Such locations correspond to Zone 2 classification to IEC 60079-0.

• The type of protection is "Ex nA IIC T4 Gc" according to IEC 60079-15.

• The 5069-AEN2TR EtherNet/IP adapter complies to standards IEC 60079-0:6th Edition, IEC-60079-15:4th Edition when used at or below 125V AC, reference IECEx certificate

number IECEx UL15.0007X.

• The 5069-AENTR and 5069-AENTRK EtherNet/IP adapter complies to standards IEC 60079-0:6th Edition, IEC-60079-15:4th Edition, reference IECEx certificate number IECEx

UL 16.0124X.

• May have catalog numbers followed by a “K” to indicate a conformal coating option
