5069-L320ER Allen Bradley MicroLogix 1000 Programmable Controllers

INQUIRE NOW

Products Name: 5069-L320ER Allen Bradley MicroLogix 1000 Programmable Controllers

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number: 5069-L320ER

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.21kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

The procedures in this section assume you have prepared your panel

and understand how to bond your system. For installation instructions

regarding other equipment and accessories, refer to the instructions

that came with each of the accessories for their specific requirements.

To mount your Ultra3000 drive:

1. Layout the position for the Ultra3000 and accessories in the

enclosure (refer to Establishing Noise Zones for panel layout

recommendations). Mounting hole dimensions for the Ultra3000

are shown in Appendix A.

2. Attach the Ultra3000 to the cabinet, first using the upper mounting

slots of the drive and then the lower. The recommended mounting

hardware is M5 metric (1/4-20) or #10 MS bolts. Observe bonding

techniques as described in HF Bonding Your System.

3. Tighten all mounting fasteners.

This drive contains ESD (Electrostatic Discharge)

sensitive parts and assemblies. You are required to

follow static control precautions when you install,

test, service, or repair this assembly. If you do not

follow ESD control procedures, components can be

damaged. If you are not familiar with static control

procedures, refer to Allen-Bradley publication

8000-4.5.2, Guarding Against Electrostatic Damage

or any other applicable ESD Protection Handbook.

IMPORTANT To improve the bond between the Ultra3000 and

subpanel, construct your subpanel out of zinc

plated (paint-free) steel.

This appendix contains the following interconnect diagrams:

• Power Interconnect Diagrams

• Shunt Module Interconnect Diagrams

• Ultra3000/Motor Interconnect Diagrams

• Control String Examples (120V ac)

• Controlling a Brake Example

• Ultra3000 to Logix Cable and Interconnect Diagrams

• Ultra3000 to IMC-S Compact Cable and Interconnect Diagram
