Relay and socket assembled interface modules for high density interposing or isolation applications
Screw terminal and spring-clamp bases
6 A relay, choice of silver or gold contacts
2 A solidstate relay — DC output
1 A solidstate relay — AC output
SPDT (relay), 1 N.O. (solid-state)
Built-in retainer clip and snap-in marker lever
Standard LED, reverse polarity protection, and surge protection ∆
Externally replaceable relay modules
Unique leakage current suppression version to address industry concerns of nuisance coil turn-on or contact non-drop out when connecting to PLCs with leakage
current
Available with hazardous location certification
Description:
Description Pkg.
Quantity
Socket Input
Voltage
Cat. No.
Replacement Relays
Order must be for 20 relays or multiples of 20.
20 12V AC/DC 700-TBR12⋆
24V AC/DC 700-TBR24⋆
48V AC/DC 700-TBR48⋆
Cat. No. 700-TBR24 110/125V AC/DC
220…240V AC/DC
700-TBR60⋆
Replacement SSR
4-blade miniature relay for use with 1 N.O. SSR DC output. Order multiples of 20.
20 24V DC 700-TBS24
48V DC, 110/125V
AC/DC
220…240V AC/DC
700-TBS60
Cat. No. 700-TBS24 Replacement SSR
4-blade miniature relay for use with 1 N.O. SSR AC output. Order multiples of 20.
20 24V DC 700-TBS124
Replacement SSR
4-blade miniature relay for use with 1 N.O. SSR AC output. Order must be for 20 relays or
multiples of 20.
20 48V DC
110/125V AC/DC
220…240V AC/DC
700-TBS160
20-Way Jumper
Can be cut to required length. Ith = 36 A max per 20-way jumper.
1 Color
Red 700-TBJ20R
Grey 700-TBJ20G
Cat. No. 700-TBJ20B Blue 700-TBJ20B
End Barrier
Used for visual inspection of groups, safe separation of neighboring 700-HL modules that end
with jumpers.
10 Black 700-HN177
Cat. No. 700HN177
Snap-in Marker
These snap-in markers have a 6 x 10 mm surface and snap into the ejection lever for the relay.
100 Blank 1492-MC6X10
Standard 1492-
MC6X10
www.ab.com/
catalogs for information
Custom ‡
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
