A-B 1794-ADN Media Adapter Module

Product Overview

The Allen-Bradley 1794-ADN is a versatile Flex I/O communication module designed to serve as a DeviceNet communication adapter. This module is specifically engineered to work seamlessly with the 1794 Flex I/O

 product family. It provides a reliable and efficient connection between DeviceNet networks and various industrial automation systems.

Key Features and Benefits

• DeviceNet Connectivity: Enables direct connection to DeviceNet networks, facilitating communication with other compatible devices on the network.

• Flex I/O Compatibility: Designed to work seamlessly with the 1794 Flex I/O system, offering flexibility in configuring and expanding I/O capabilities.

• 24 VDC Operation: Powered by a standard 24 VDC supply, making it suitable for a wide range of industrial applications.

• Robust Construction: Built to withstand harsh industrial environments, ensuring reliable performance in demanding conditions.

• Easy Configuration: Simple to configure and integrate into existing automation systems, reducing installation time and effort.

Technical Specifications

• Voltage: 24 VDC

• Communication: DeviceNet

• Compatibility: 1794 Flex I/O

• Environmental: Meets relevant industry standards for industrial environments

Precautions

• Power Supply: Ensure a stable and reliable 24 VDC power supply is provided.

• Grounding: Proper grounding is essential to prevent electrical noise and interference.

• Compatibility: Verify compatibility with other devices on the DeviceNet network before installation.

• Installation: Follow the manufacturer's installation instructions carefully to ensure correct and safe operation.

Applications

The 1794-ADN module finds extensive use in various industrial automation applications, including:

• Machine Automation: Connecting sensors, actuators, and other devices in automated machinery.

• Process Control: Monitoring and controlling industrial processes.

• Material Handling: Controlling conveyors, robotic arms, and other material handling equipment.

• Packaging: Automating packaging processes, including filling, sealing, and labeling.

Additional Information

For more detailed information, including specific technical specifications, certifications, and troubleshooting guidelines, please refer to the official product documentation provided by Rockwell Automation.

Note: To obtain the most up-to-date and comprehensive information, it is recommended to visit the Rockwell Automation website or consult with a Rockwell Automation authorized distributor.
