A-B  1797-BCNR

Detailed Product Description

The Allen Bradley 1797-BCNR is a specialized ControlNet barrier module designed to facilitate communication between standard ControlNet networks and ControlNet Ex networks in hazardous environments. This module serves as a crucial interface, ensuring safe and reliable data transmission while adhering to strict safety standards.

Key Features and Specifications

• IIC IS Module Type: Complies with the International Electrotechnical Commission (IEC) standards for intrinsic safety, making it suitable for use in hazardous areas classified as Zone 0.

• 7V ControlNet Ex System Power: Operates on a 7-volt ControlNet Ex system power supply, providing the necessary energy for communication.

• ControlNet Communication Port: Equipped with a dedicated ControlNet communication port for seamless integration into existing ControlNet networks.

• Maximum 5 Mbps: Supports a maximum data transfer rate of 5 megabits per second, ensuring efficient communication between devices.

• Redundancy: Offers redundant functionality, enhancing system reliability and minimizing downtime in the event of a failure.

• BNC Connectors: Features BNC connectors for secure and easy cable connections.

Benefits

• Safety: Ensures the safety of personnel and equipment in hazardous environments by providing intrinsic safety.

• Reliability: Redundant design enhances system reliability and minimizes downtime.

• Compatibility: Seamlessly integrates with existing ControlNet networks.

• Efficiency: Supports high-speed data transfer for efficient communication.

• Compliance: Adheres to international safety standards for use in hazardous areas.

Precautions

• Installation: Must be installed in a safe area of the system according to the manufacturer's instructions.

• Connections: BNC connectors should only be connected when the system is powered off.

• Environment: Suitable for use in hazardous areas classified as Zone 0.

• Maintenance: Regular inspection and maintenance are recommended to ensure optimal performance.

Applications

The 1797-BCNR is commonly used in various industries where hazardous conditions exist, such as:

• Oil and gas: Monitoring and control of processes in hazardous areas.

• Chemical processing: Automation of equipment in hazardous environments.

• Mining: Remote monitoring and control of mining operations.

• Power generation: Automation of power generation facilities in hazardous areas.

Additional Information

• Part Numbers: 10612598293657 UPP Ser A

• Availability: Widely available from authorized distributors and online retailers.

Note: For detailed installation instructions, technical specifications, and compatibility information, please refer to the official product documentation provided by Allen Bradley.
