ATTENTION: This equipment is sensitive to electrostatic discharge, which can
cause internal damage and affect normal operation. Follow these guidelines
when you handle this equipment:
• Touch a grounded object to discharge potential static.
• Wear an approved grounding wriststrap.
• Do not touch connectors or pins on component boards.
• Do not touch circuit components inside the equipment.
• Use a static-safe workstation, if available.
• Store the equipment in appropriate static-safe packaging when not in use.
Description:
Number of inputs per
expansion block
8 points, non-isolated, sinking or sourcing
Indicators 8 green status
Common type 8 points/2COM (non-polarity)
On-state voltage 9.6V DC min
24V DC nom
28.8V DC max
Off-state voltage, max 5.0V DC
On-state current, max 8 mA per point @ 28.8V DC
Nominal input impedance 4.8 K
Input signal delay, max
OFF to ON
ON to OFF
10 ms
10 ms
Output Specifications
Number of outputs per
expansion block
8 points, non-isolated, sinking 8 points, non-isolated, sourcing
Indicators 8 green status
Common type 8 points/2COM (non-polarity)
On-state voltage 10V DC min
24V DC nom
28.8V DC max
On-state voltage drop,
max 0.5V DC
On-state current, min 1 mA per channel
Off-state leakage, max 0.5 mA
