AB 2711P-RP8A

The logic module has these features:

• Status indicators

• Input power, DC or AC

• Ethernet port, serial port, two USB ports, CompactFlash card slot

• RAM and internal CompactFlash with firmware or operating system

Description:

Follow these steps to install or replace RAM.

1. Turn the logic module over to expose the circuit board.

2. Locate the RAM module on the circuit board.

3. Pull the metal retaining clips away from the module and slide out the RAM module.

4. Insert the new RAM module at a 45° angle and snap down.

1. Turn the logic module over to expose the circuit board.

2. Unscrew and remove the retaining clip that secures the internal CompactFlash card.

3. Pull out the internal CompactFlash card.

4. Insert the new internal CompactFlash card.

5. Reattach the retaining clip.

When you connect or disconnect the battery, an electrical arc can occur. This could cause WARNING an explosion in hazardous location installations. Be sure that power is removed or the

area is nonhazardous before proceeding.

For safety information on the handling of lithium batteries, including handling and

disposal of leaking batteries, see Guidelines for Handling Lithium Batteries, publication

AG 5-4. Replace the battery only with the indicated catalog number.

Do not dispose of battery in a fire or incinerator. Dispose of used batteries in accordance

with local regulations.

Store batteries in a cool, dry environment. We recommend 25 °C (77 °F) with 40…60%

relative humidity. You may store batteries for up to 30 days between -45…85 °C

(-49…185 °F), such as during transportation. To avoid possible leakage, do not store

batteries above 60 °C (140 °F) for more than 30 days.
