AB 500-DOD930

Note: additional control circuit overcurrent protection may be required. refer to the National Electrical Code.

The current rating of the control circuit conductors furnished with this device is 15 amperes for sizes 0 through 3 and 20

amperes for size 4.

Maintain this equipment in accordance with guidelines of NFPA-70b, Electrical Equipment Maintenance.

Description:

140G-J and 140MG-J may be substituted for 140G-I and 140MG-I

 (at the same ratings), respectively.

 140G-H and 140MG-H may be substituted for 140G-G and and 140MG-G

 (at the same ratings), respectively.

 Number after “G” can be 6,

 Number after “H” can be 6, 0 or 15,

 Number after “I” can be 2 or 3,

 Number after “J” can be 6 or 0.

 * Rating 100A for 140G-H/HC_-D10 or 150A for 140G-J/JC_-D15

b) * Includes all contactor variations following the Size letter, and starter

 variations with eutectic or E1 Plus overload relays (except .2 - 1 FLA range)

a) ** Includes suffixes A*, B*, C* & D*. Refer to note b.

d) For Size 0, combinations with 140G-* circuit breakers include starters with

 eutectic overloads (not E1 Plus)

1) The ratings shown are in accordance with UL 508 and CSA C22.2 No. 14

4) Suitable for use on a circuit capable of delivering not more that 5,000 RMS

 for size 0,1,2,3 and not more that 10,000 RMS symmetrical amperes,

 600 V max.

2) The devices and ratings shown are those most commonly needed;

 additional ratings may be available

3) Additional limitations may apply. Refer to applicable national and local

 electrical codes
