AB 800T-H2

Flashing Lamp (6V): 800T-N212 Available for any illuminated device which uses the ANSI No. 755 or No. 1866 lamp.

Lamp Installer: 800T-N82 Useful for installation or replacement of incandescent lamps

LED Lamps and Power Modules for extended lamp life:

(Consult A-B Catalog for ordering information)

Description:

To determine the contact targets of Allen-Bradley 800T and 800H Momentary Push Buttons, 2 and 3 position Push-Pull Push Buttons, and 2 position Twist-release Push Buttons, proceed as follows.

1. Identify the CONTACT BLOCK used by looking at the contact block cover plate and finding a Catalog No. such as 800T-XA.

2. Identify the CIRCUIT for which the contact target is desired by looking again at the contact block cover plate for a wiring symbol such as “A”, “B”, “A1”, etc.

3. Refer to Fig 5 and find the contact block and wiring symbol.

Read across the top to find the Lens or Cap position. (IN, CENTER, or OUT)

The contact target is at the intersection of the contact block row and position column.

WARNING: OnlySealed Switch and Logic Reed Blocks may be used on devices rated for Class I, Division 2 Hazardous Locations.

Substitution of the contact block may impair suitability for Division 2.

Exposure to some chemicals may degrade the sealing properties of materials used in the sealed contact blocks.

Normally Open (NO) contacts, sealed switch contact blocks and logic reed contact blocks can not be used for emergency stop control circuits.
