ABT-TD20942-P4 Allen Bradley Servo driver

INQUIRE NOW

Products Name: ABT-TD20942-P4 Allen Bradley Servo driver

PRODUCT DESCRIPTION

Brand:  Allen Bradley

Model number:ABT-TD20942-P4

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.53kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

To ground the switch to earth ground, follow these steps. Be sure to follow any grounding requirements at your site.

1. To remove the ground screw from the front panel of the switch, use a Phillips screwdriver or a ratcheting torque screwdriver with a Phillips head.

Store the ground screw for later use.

2. Use the guidelines from the manufacturer to determine the wire length to be stripped.

3. Insert the ground wire into the ring terminal lug and use a crimping tool to crimp the terminal to the wire.

If you are using two ring terminals, repeat this action for the second ring terminal.

4. Slide the ground screw through the terminal.

5. Insert the ground screw into the functional ground screw opening on the front panel.

6. Use a ratcheting torque screwdriver to tighten the ground screws and ring terminal lugs to the switch front panel to 0.4 Nm (3.5 inlb).

Do not exceed the recommended torque.

7. Attach the other end of the ground wire to a grounded bare metal surface, such as a ground bus, a grounded DIN rail, or a grounded bare rack.

. Measure a length of 0.82…0.52 mm2

 (18…20 AWG) copper wire long enough to connect to the DC power source.

2. Using an 18-gauge wire-stripping tool, strip each of the two wires to 6.3 mm (0.25 in.) ± 0.5 mm (0.02 in.).

Do not strip more than 6.8 mm (0.27 in.) of insulation from the wire. Stripping more than the recommended amount of wire can leave wire exposed after installation.

3. Locate the power connector.

Application Power Input per Port Power Consumption Allen-Bradley® Products

PoE only

IEEE 802.3af 44…57V DC (48V DC, nom) 15.4 W, max Switched mode power supplies: • 1606-XL Standard • 1606-XLE Essential

• 1606-XLP Compact • 1606-XLS Performance

PoE and PoE +

IEEE 802.3 at Type 2 50…57V DC (54V DC, nom) 15.4 W, max for PoE

30 W, max for PoE+

IN1—External Device Connection

1.REF—External Device Connection 2

12 Rockwell Automation Publication 1783-IN016C-EN-P - August 2022

Stratix 5700 Ethernet Managed Switches Installation Instructions

4. Insert the exposed part of the positive wire into the DC+ connection and the exposed part of the return wire into the DC- connection.

Make sure that you cannot see any wire lead. Only wire with insulation can extend from the connector.

5. Use a ratcheting-torque screwdriver to torque the captive screws of the power connector to 0.23 N•m (2.0 in•lb).

6. Connect the other end of the positive wire (the one connected to DC+) to the positive terminal on the DC power source.

7. Connect the other end of the return wire (the one connected to DC-) to the return terminal on the DC power source
