Allen-Bradley 1444-TB-A

• Power boost up to 6 A

• High overload current, no switch-off

• Wide-Range Input

• Robust mechanics and EMC

Description:

Input voltage AC100...120/200...240V (switchable), 47...63 Hz

(85...132V AC / 176...264V AC, 210...375V DC,

see also“Output: Continuous Loading”)

Wide-Range Input: With the switch in the 230V position the power-supply unit operates at low and moderate loads (until 3 A) at any input voltage between 95 and

264V AC (see ‘Output’ below).

Note: At DC input, always leave the switch in the 230V position

Input current < 2.6 A (switch in 115V position)

< 1.4 A (switch in 230V position)

• DCin at open output typ. 5 mA (preserves battery sources)

Inrush current typ. 15 A at 264V AC and cold start

If you intend to protect the primary side of the power supply with a fuse or a circuit

breaker, a 10 A slow acting fuse (HBC) or a supplementary protector 1492-

SPU1C100 is recommended. In order to meet local requirements, please consult local codes and regulations for proper installation.

EN 61000-3-2 (harmonic current emissions) is fulfilled

Transient

handling

Transient resistance acc. to VDE 0160 / W2 (750 V /

1.3 ms), for all load conditions.

Hold up time > 37 ms at 196VAC, 24V/5 A

(see Diagram)

Efficiency typ. 90 % (230V AC, 24V/ 5 A)

Losses typ. 13,3 W (230V AC, 24V/5 A)

MTBF 520,000 h acc. to Siemensnorm SN 29500

(24V/5 A, 230V AC, Tamb = +40 °C)

Life cycle (electrolytics) The unit exclusively uses longlife electrolytics, specified for +105°C.

Startup delay typ. 0.1 s

Rise time ca. 5...20 ms, depending on load
