ATTENTION: ControlLogix 5580 and 5570 conformal coated products are shipped with port protection plugs installed to
provide a layer of protection from corrosive environments. In order to meet the corrosive atmospheres. Port plugs must
remain installed in unused ports at all times during storage and operation for the product to meet its corrosive
atmosphere rating. If temporary access is required, plugs can be removed, and should be reinserted after temporary
access is complete.
ontroller tasks • 32 tasks, including a combination of continuous (1), periodic, and event tasks
• 100 programs/task
Built-in communication ports 1 port RS-232 serial
Communication options
• EtherNet/IP
• ControlNet
• DeviceNet
• Data Highway Plus
• Remote I/O
• SERCOS
• Third-party process and device networks
Serial port communication
• ASCII
• DF1 full/half-duplex
• DF1 radio modem
• DH-485
• Modbus via logic
Controller connections supported max
(1)
(1) ControlLogix 5560 controllers use connections to establish communication links between devices. For more information on connections, see the ControlLogix System User Manual,
publication 1756-UM001.
250
Network connections, per network module
• 528 EtherNet/IP; 512 TCP (1756-EN4TR)
• 256 EtherNet/IP; 128 TCP (1756-EN2x)
• 128 EtherNet/IP; 64 TCP (1756-ENBT)
• 100 ControlNet (1756-CN2/A)
• 40 ControlNet (1756-CNB/D, 1756-CNB/E)
• 128 ControlNet (1756-CN2/B)
Controller redundancy Full support
Integrated motion
• SERCOS interface
• Analog options (encoder input, LDT input, SSI input)
• Integrated Motion on the EtherNet/IP network
Programming languages
• Relay ladder logic
• Structured text
• Function Block Diagram
• Sequential function chart (SFC)
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
