ALLEN BRADLEY 1756-L8SP

WARNING:

Explosion Hazard –

• Do not disconnect equipment unless power has been

removed or the area is known to be nonhazardous.

• Do not disconnect connections to this equipment unless

power has been removed or the area is known to be

nonhazardous. Secure any external connections that mate

to this equipment by using screws, sliding latches,

threaded connectors, or other means provided with

this product.

• Substitution of components may impair suitability for

Class I, Division 2.

• If this product contains batteries, they must only be

changed in an area known to be nonhazardous.

Description:

ATTENTION:

• In case of malfunction or damage, no attempts at repair should be made. The module should be returned to the manufacturer for repair.

Do not dismantle the module.

• The USB port is intended for temporary local programming purposes only and not intended for permanent connection. The USB cable is not to exceed

3.0 m (9.84 ft) and must not contain hubs.

• Use only a soft dry anti-static cloth to wipe down equipment. Do not use any cleaning agents.

• When GuardLogix and GuardLogix Conformal Coated controllers are installed in a 1756 Series C Chassis, this equipment is certified for use only within the

surrounding air temperature range of 0…60 °C (32…140 °F). The equipment must not be used outside of this range.

• When GuardLogix and GuardLogix Conformal Coated controllers are installed in a 1756 Series B Chassis, this equipment is certified for use only within the

surrounding air temperature range of 0…50 °C (32…122 °F). The equipment must not be used outside of this range.

• When GuardLogix XT controllers are installed in a ControlLogix-XT™ Series C Chassis, this equipment is certified for use only within the surrounding air temperature range of -25…+70 °C (-13…+158 °F). The equipment must not be used outside of this range.

WARNING:

• When you press the reset button while power is on, an electrical arc can occur. This could cause an explosion in hazardous location installations. Be sure

that power is removed or the area is nonhazardous before proceeding.

• Do not use the USB port in hazardous locations.
