ALLEN BRADLEY 2711P-B6C20D

This publication provides information about how to convert the following terminals to the new generation

PanelView™ Plus 6 terminals:

• PanelView Plus and PanelView Plus CE 700…1500 terminals

• PanelView Plus 400 and 600 terminals

• PanelView Plus Compact terminals

The new PanelView Plus 6 platform is available with or without extended features and file viewers. There is no longer a

distinction between PanelView Plus and PanelView Plus CE terminals.

Description:

Operating system Windows CE 6.0 – Windows CE 6.0 Windows CE 4.1

FactoryTalk® View ME

Station (runtime) software Version 6.10 or later Version 3.20…5.10 Version 6.0 or later Version 3.20…5.10

FactoryTalk ViewPoint

software No No Version 1.2 or later Version 1.2 on series E or later

terminals, requires 128 MB RAM

Application compatibility Supports FactoryTalk View ME

applications, version 3.2 or later

Supports FactoryTalk View ME

applications, version 3.20…5.10

Supports FactoryTalk View ME

applications, version 3.2 or later

Supports FactoryTalk View ME

applications, version 3.20…5.10

Open architecture Yes – Yes Yes

.Net Compact framework Version 3.5 Version 1.1, not installed Version 3.5 Version 1.1, not installed

File system Datalight Reliance with FAT

support – Datalight Reliance with FAT

support FAT16, FAT32, on 512 MB version

CPU ARM, 1.0 GHz NEC VR5532A MIPS, 350 MHz x86, 1.0 GHz x86, Intel Celeron, 650 MHz

RAM 256 MB DDR2 (chip onboard)

4264 MiB/s peak

64 MB PC100 SDRAM SODIMM

800 MiB/s peak

512 MB DDR2 (chip onboard)

4264 MiB/s peak

64, 128, 256, or 512 MB,

PC100 SDRAM SODIMM

800 MiB/s peak

Internal storage 512 MB nonvolatile memory

(approx. 73 MB free user memory) 64 MB 512 MB nonvolatile memory

(approx. 79 MB free user memory) 64 MB, 128 MB, or 256 MB

Real-time clock Yes Yes Yes Yes

Interfaces

Secure Digital (SD) slot 1 Secure Digital high-capacity

(SDHC) slot supports 1784-SDx

cards

–1 Secure Digital high-capacity

(SDHC) slot supports 1784-SDx

cards

–CompactFlash (CF) slot – 1 CF Type I – 1 CF Type I

USB ports 1 USB-A, V2.0 high speed

1 USB-B, V2.0 high-speed, 4-pin 1 USB-A, V1.1 2 USB-A, 2.0 high speed 2 USB-A, V1.1

PCI – – 1 PCI, 3.3/5V 32-bit 1 PCI, 3.3/5V 32-bit

Communication Interfaces

Ethernet (1) 10/100 Mbps, Auto-MDI/MDI-X (1) 10/100 Mbps (1) 10/100 Mbps, Auto-MDI/MDI-X (1) 10/100 Mbps

RS-232 (1) DB9 (1) DB9 (1) DB9 (1) DB9

ControlNet – Add-on communication module Add-on communication module Add-on communication module

DH+™ – Add-on communication module Add-on communication module Add-on communication module

DH-485 – Add-on communication module Add-on communication module Add-on communication module

Remote I/O – Add-on communication module – Add-on communication module

DeviceNet – Add-on communication module – Add-on communication module

Input power Noninsolated DC voltage

or AC voltage

Nonisolated DC voltage

or AC voltage

Isolated DC voltage

or AC voltage

Isolated DC voltage, nonisolated DC

voltage, or AC voltage
