Allen-Bradley 5069-IB16

Based on your application design, you must install a CompactLogix 5380 controller,

CompactLogix 5480 controller, Compact GuardLogix 5380 controller, or a

Compact 5000 I/O EtherNet/IP™ adapter before you can install the module.

The following applies to products with IECEx certification: Such modules:

• Are intended for use in areas in which explosive atmospheres caused by gases, vapors, mists, or air are unlikely to occur, or are likely to occur only infrequently and for

short periods. Such locations correspond to Zone 2 classification to IEC 60079-0.

• The type of protection is "Ex ec IIC T4 Gc" according to IEC 60079-7.

• The 55069-IB16, 5069-IB16F, and 5069-IB16K modules comply to standards IEC 60079-0:7th edition, IEC-60079-7:5.1 Edition, reference IECEx certificate number IECEx UL

15.0055X.

• May have catalog numbers followed by a “K” to indicate a conformal coating option.

• Do not wire more than 1 conductor on any single RTB terminal.

• In case of malfunction or damage, no attempts at repair should be made. The module should be returned to the manufacturer for repair. Do not dismantle

the module.

• This equipment is certified for use only within the surrounding air temperature range of 0…60 °C (32…140 °F) The equipment must not be used outside of

this range.

• Use only a soft dry anti-static cloth to wipe down equipment. Do not use any cleaning agents.

WARNING:

• This equipment is not resistant to sunlight or other sources of UV radiation.

• This equipment shall be mounted in an ATEX/IECEx Zone 2 certified enclosure with a minimum ingress protection rating of at least IP54 (as defined in

EN/IEC 60079-0) and used in an environment of not more than Pollution Degree 2 (as defined in EN/IEC 60664-1) when applied in Zone 2 environments. The

enclosure must be accessible only by the use of a tool.

• This equipment shall be used within its specified ratings defined by Rockwell Automation.

• Provision shall be made to prevent the rated voltage from being exceeded by transient disturbances of more than 140% of the rated voltage when applied in

Zone 2 environments.

• The instructions in the user manual shall be observed.

• This equipment must be used only with ATEX/IECEx certified Rockwell Automation backplanes.

• Secure any external connections that mate to this equipment by using screws, sliding latches, threaded connectors, or other means provided with this

product.

• Do not disconnect equipment unless power has been removed or the area is known to be nonhazardous.

• Earthing is accomplished through mounting of modules on rail.

• Devices shall be used in an environment of not more than Pollution Degree 2.
