CPBH00000000D5 A-B

The MicroLogix 1100 is particularly well

suited to meet the needs of SCADA RTU,

packaging, and material handling

applications. With even more memory for

data logging and recipe than the

MicroLogix 1500, the MicroLogix 1100 is

great for remote monitoring and for

applications that are memory intensive, but

require limited I/O.

Description:

• Online editing

• Built-in 10/100 Mbps EtherNet/IP port for messaging

• Isolated RS-232/RS-485 combo port

• Ten digital inputs, two analog inputs, six digital outputs on each controller

• One embedded 40kHz high-speed counter (on controllers with dc inputs)

• Two 40kHz high-speed PTO/PWM outputs (on controllers with dc outputs)

• Embedded LCD for controller and I/O status and simple operator interface

for messages, and bit/integer monitoring and manipulation

• 4K words user program memory and 4K words user data memory

• Up to 128K bytes for data logging and 64K bytes for recipe

• Embedded Web server

• Email support

• CIP generic messaging support

The MicroLogix 1100 combines all the features you demand in a compact controller,

with EtherNet/IP messaging, online editing, a built-in LCD screen on every controller

and a versatile combination of I/O.

The embedded 10/100 Mbps EtherNet/IP port for peer-to-peer messaging offers users

high speed connectivity between controllers and the ability to access, monitor and

program from the factory floor to anywhere an Ethernet connection is available.

An embedded Web server allows a user to custom configure data from the

controller to be displayed as a web page. Furthermore, a second RS-232/RS-485

combo port provides a host of different point-to-point and network protocols.

With online editing, modifications can be made to a program while it is

running, making fine tuning of an operating control system possible, including

PID loops.
