The reset button is located below the USB ports on the bottom of the housing. It can be pressed with any small
pointed object (e.g. paper clip). Pressing the reset button triggers a hardware reset, which means:
• All application programs are stopped.
• All outputs are set to zero.
The PLC then boots into Service mode by default. The boot mode that follows after pressing the reset button can
be defined in Automation Studio.
Description:
Based on state-of-the-art Intel® ATOM™ processor technology, the X20 CPUs cover a wide spectrum of demands.
They can be implemented in solutions ranging from standard applications to those requiring the highest levels of
performance.
The series starts with Intel® ATOM™ processor 333 MHz compatible models – X20CP1583 and X20CP3583. With
an optimum price/performance ratio, it has the same basic features as all of the larger CPUs.
The basic model includes USB, Ethernet, POWERLINK V1/V2 and removable CompactFlash. The standard Ethernet
interface is capable of handling communication in the gigabit range. For improved real-time network performance,
the onboard POWERLINK interface supports poll response chaining mode (PRC).
In addition, there are up to three multi-purpose slots for additional interface modules.
• Intel® ATOM™ 1600/1000/600 Performance with integrated I/O processor
• Entry-level CPU is Intel® ATOM™ 333 MHz-compatible with integrated I/O processor
• Ethernet, POWERLINK V1/V2 with poll response chaining and onboard USB
• 1 or 3 slots for modular interface expansion
• CompactFlash as removable application memory
• Up to 512 MB DDR2-SRAM according to performance requirements
• CPU redundancy possible
• Fanless
• Extremely compact
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
