Bachmann MX220

Intervals that can be retrieved via function calls in the user application: 100 µs,

200 µs, 400 µs, 800 µs, 1.6 ms (via block access)

Processor modules of the MX200 series combine outstanding environmental

robustness with very compact dimensions.

Thanks to an integrated power supply unit, which can also provide

 the I/O module power supply and integrated communication

interfaces, complete basic system can be implemented on only

2  module widths. The industrial processors used with scalable

clock frequencies offer sufffcient CPU performance for small to

medium-sized applications.

Machine control, simple motion control, a wide range of communication

 tasks or condition monitoring can be implemented easily

and cost efffciently with this platform. Different programs can be

executed virtually in parallel thanks to the real-time multi-tasking.

If the CPU performance has to be increased, applications can be

transferred easily to more powerful CPU models thanks to the

standard programming model.

The generous thermal design and special coating processes enable

fan-free use in extreme operating conditions from -30 to +60 °C.

• Industrial Processor at up to 433 MHz

• Priority scheduled Multitasking

• 256 MB RAM

• 512 kB remanent memory (Retain)

• 64 MB internal memory device 

1)

• CompactFlash card slot for removable media

• Front side PC-Card slot

• 2x Ethernet 10/100 Mbit/s

• 1x RS232, 1x RS232/RS422/RS485, 1x USB 2.0

• CAN/CANopen

• Integrated power supply for I/Os
