Bender RCMA470LY

The AC/DC sensitive residual current monitor RCMA470LY is designed for monitoring earthedpower supply systems (TN and TT systems) where DC fault currents or residual currents con-tinuously greater than zero may occur, These are in particular loads containing six-pulserectifiers or one way rectifiers with smoothing, such as converters, battery chargers, con-struction site equipment with frequency-controlled drives.The prewarning stage (50 96 of the set response value lAn1) allow to distinguish betweenprewarning and alarm. Since the values are measured with measuring current transformersthe device is nearly independent of the load current and the nominal voltage ofthe system.The device can also be used for busbar systems.

External measuring current transformerTwo separately adjustable response values,Alarm lΔn1: 30 mA...3 A (0...150 Hz)prewarning lAn2: 50 %6/100 96 of lAn1Adjustable response delay 0...10 s(prewaming 0/1 s)

Two separate alarm relays with onechangeover contact each

N/0 or N/C operation

Fault memory

Combined TEST and RESET buttonConnection external TEST and RESETbutton

LED bar graph indicator lAn 0...100 %Connection external measuring instrument lán 0...100 %

CT connection monitoringSealable transparent cover

Separate supply voltage

Type B acc. to lEC 60755

AC/Dc sensitive residual current moni-Construction site equipmenttoring in earthed two, three or four con-Wood working machinesductor systems.Battery systemsComputer tomographsLaboratory equipmentPhotovoltaic systemsFurniture industryUninterruptible power supply systems (UPS)Sewage works

AC/DC sensitive current monitoring ofsingle conductors de-energized undernormal conditions (e.g.N and PE conductors).

Variable-speed drives

Function

Residual current monitoring takes place via an external measuring current transformer. Whenthe residual current respectively the current exceeds the set response value, the alarm LEDlights and the associated alarm relay switches when the response delay has elapsed.The alarm messages are stored. The fault memory can be reset by pressing the RESET button.The device function can be tested using the TEST button.The currently measured value in per cent related to the set response value is shown on theLED bar graph indicator. The CT circuit is continuously monitored. in case of wire breakage,.the alarm relay switches and the Power On LED flashes.
