IR1575W-435 Bender  I/O module  In Stock

Once the supply voltage US is applied, the start-up delay is activated. Measured values

changing during this time do not influence the switching state of the alarm relays.

Residual current measurement takes place via an external measuring current transformer

of the CTUB100 series. The currently measured value is shown on the LC display. In this

way any changes, for example when circuits are connected to the system, can be recognised

 easily.

1 - Power On LED “ON” (green); lights when supply voltage is

applied and flashes in the event of system fault alarm

respectively in the event of CT malfunction.

2 - Alarm LED “AL1” (yellow), prewarning; lights when the set

response value IΔn1 is exceeded or flashes in the event of

system fault alarm respectively in the event of CT malfunction

3 - Alarm LED “AL2” (yellow), alarm; lights when the set response

value IΔn2 is exceeded or flashes in the event of system fault

alarm respectively in the event of CT malfunction.

4 - Multi-functional LC display

5 - Test button “T”: to call up the self test.

Arrow up button: parameter change, to move up in the menu

6 - Reset button “R”: to delete saved alarms.

Arrow down button: parameter change, to move down in the

menu

7 - “MENU” button: to call up the menu system.

Enter button: to confirm parameter change.

“ESC” button: press the button > 1.5 seconds.

Product details:

IR1575W-435 Bender  I/O module
