When the insulation resistance from system to ground falls below the set response value,
the alarm relays switch and the alarm LEDs activate. Two separately adjustable alarmcontacts
can be set to a prewarning and main warning alarm. The measured value is indicated
on the LCD display or an externally connectable measuring instrument.
Description:
• History memory with real-time clock to store up to 300 timestamped event records
• Galvanically isolated RS-485 interface (BMS protocol) for data exchange with other
Bender devices and communication systems
• Standby contacts and RS-485 communication for operating multiple ground fault detectors
in systems tied together with tiebreakers or interlocks
• Galvanically isolated analog output, 0(4 ) - 20 mA
1 - INFO key: displays pertinent system information
ESC key: Goes back a step inside device's menu
2 - TEST button: Activates self-test
Arrow up key: Scrolls up inside device's menu
3 - LCD display
4 - RESET button: Resets device
Arrow down key: Scrolls down inside device's menu
5 - MENU key: Activates device's internal menu
Enter key: Confirm change inside device's menu
6 - Alarm LED 1 lights: Alarm, Prealarm
7 - Alarm LED 2 lights: Alarm, Main alarm
8 - System fault LED: Lights on connection or device error
9 - IRDH275: Analog output, electrically isolated: 0 - 400 µA
IRDH275B: Analog output, electrically isolated:
0 - 20 mA or 4 - 20 mA
10 - RS-485 interface:
IRDH275: One-way ASCII stream with measurement status
IRDH275B: Two-way communication with other BENDER
devices, including communication gateways
11 - Alarm relay 1, normally energized or de energized contact
12 - Alarm relay 2/System Fault Relay, normally energized or deenergized
contact
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
