Brand： BENDER
Model number： RCMA421 H-D-2
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.16kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
The universal remote alarm indicator and test combination MK2430 is designed for visual
and audible indication of alarm messages from Bender systems such as EDS, RCMS and
MEDICS. In MEDICS monitoring systems, the MK2430 meets the requirements of IEC 60364-7-
710 and DIN VDE 0100-710:2002-11 in respect of test functions for IT system monitoring
and alarms from changeover modules.
The IT system monitoring equipment can be tested using the programmable test button.
Important display functions:
The LC text display makes this information easy to understand. The connection between
the MKs and the changeover and monitoring modules is implemented with bus technology.
During normal operation, the MK2430 indicates the readiness for operation of the system.
The MK2430-11 features 12 digital inputs allowing messages from third party systems to
be recorded and displayed on the MK2430, for example from medical gases or UPS systems
(special safety power supply sources).
Function description
On its backlit LC display (4 x 20 characters), the MK2430 displays messages from all BMS
bus devices assigned via alarm addresses. As well as being used as a standalone indicator
the MK2430 also supports parallel operation. In the event of an alarm message, the yellow
“WARNING” LED or the red “ALARM” LED lights up and the message appears on the LC
display in plain text format. At the same time there is an audible signal (acknowledgeable).
If a second message is received whilst the first is still pending, the audible signal will
sound again and the messages will flash up alternately on the LC display. The address of
the device triggering the alarm can also be called up. The audible signal sounds again
once a configurable period of time has elapsed.
Internal device parameters (alarm addresses, test addresses,…) and the parameter setting
of EDS and RCM systems can be accessed via the menu system.
As a master, the MK2430 can also be used in installations with a number of IT and EDS
systems.
The test button can be used to check the operation of an ISOMETER® isoMED427P or IRDH.
A message is only output on the MK2430 on which the test button was pressed.
When wiring the bus connection, please note that a 4-wire cable (2 x BUS, 2 x US) with a
suitable cross section is required when the supply voltage US is incorporated in the cable.
Display/operating elements
The backlit display features four lines of 20 characters. It supplies medical and technical
personnel with information that is always clear and unambiguous, in order to help them
to make decisions. Every alarm message comprises three lines which appear spontaneously
and three additional lines which can be displayed at the touch of a button. The fourth
line contains status information (number of messages, test procedures, menu information).
Three LEDs are located above the text display. They indicate: normal operation (green),
warnings (yellow) or alarms (red). Five buttons are available for acknowledging alarms
and warnings, and for the menu system.
Remote alarm indicator and test combination with LC display
• Normal operation indicator (green LED)
• Insulation fault
• Overload
• Overtemperature
• Messages from insulation fault locators
(EDS) and residual current monitoring
systems (RCMS)
• Supply line failure
• Interruption of the phase conductor or
PE conductor of the ISOMETER®
• Power supply fault conditions and
changeover system faults
• Device failure
• Test results
• Measured values
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Related products:
IRDH275-435
