Application Advisory: The 3300 XL 11 mm Proximity Transducer is designed for measuring position
or vibration within a frequency range of 0 to 8 kHz. Typical applications of this system include radial
vibration and position, axial position and Keyphasor measurements.
Although the terminals and connector on the Proximitor sensor have protection against electrostatic
discharge, take reasonable precautions to avoid electrostatic discharge during handling.
Description:
The 3300 XL 11 mm Proximity Transducer System consists of:
• 3300 XL 11 mm probe
• 3300 XL 11 mm extension cable
• 3300 XL 11 mm Proximitor® Sensor1
The 3300 XL 11 mm Proximity Transducer System has a 3.94 V/mm (100 mV/mil)
output for non-contacting vibration and displacement measurements on fluid
film bearing machines. The large 11 mm tip enables this transducer system to
have a longer linear range compared to our standard 3300 XL 8 mm Transducer
System. It is primarily used in the following applications where the longer linear
range is necessary:
• Axial (thrust) position measurements
• Ramp differential expansion measurements on steam turbines
• Rod position or rod drop measurements on reciprocating compressors
• Tachometer and zero speed measurements
• Phase reference (Keyphasor®) signals
The 3300 XL 11 mm Proximitor Sensor is designed to replace the 7200-series 11
mm and 14 mm Transducer Systems. When upgrading from the 7200-series
system to the 3300 XL 11 mm system, every component must be replaced with
3300 XL 11 mm components. In addition, the monitoring system must be
updated. If using a 3500 Monitoring System, an updated version of the
configuration software that lists the 3300 XL 11 mm Transducer System as a
compatible option is required. Existing 3300 Monitoring Systems may need a
modification. Contact your local sales and service representative for assistance.
