Home / Products / Bently Nevada / 3500/22-01-02-00 BENTLY

3500/22-01-02-00 BENTLY

Brand: BENTLY

Model number: 3500/22-01-02-00

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.40kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

3500/22-01-02-00 BENTLY Analog Output Module



INQUIRE NOW

Products Name: 3500/22-01-02-00 BENTLY

PRODUCT DESCRIPTION

Each Keyphasor Module

accepts up to two transducer

signals from proximity probe

transducers or magnetic

pickups. The input signal

range is +0.8 V to -21.0 V

(NonIsolated I/O modules) or

+5V to -11V (Isolated I/O

modules). Signals exceeding

this range are limited

internally by the module.

Passive magnetic pickups

require a shaft rotative speed

greater than 200 rpm (3.3 Hz).

Description:

The 3500/25 Enhanced Keyphasor Module is a half-height,

two-channel module used to provide Keyphasor signals to

the monitor modules in a 3500 rack. The module receives

input signals from proximity probes or magnetic pickups and

converts the signals to digital Keyphasor signals that indicate

when the Keyphasor mark on the shaft coincides with the

Keyphasor transducer. The 3500 Machinery Protection

System can accept up to four Keyphasor signals for normal

configuration and up to eight Keyphasor signals in a paired

configuration.

Keyphasor signal is a once-per-turn or multipleevent-per-turn

pulse from a rotating shaft or gear

used to provide a precise timing measurement. This

allows 3500 monitor modules and external

diagnostic equipment to measure shaft rotative

speed and vector parameters such as 1X vibration

amplitude and phase.

The Enhanced Keyphasor Module is an improved 3500

system module. It offers expanded Keyphasor signal

processing capabilities over the previous design while

maintaining complete downward-compatibility in terms of

form, fit and function with existing Keyphasor modules for use

in legacy systems. The Keyphasor module, PWA 125792-01, is

completely replaced by the updated 149369-01 module.

When a system Keyphasor input is required for Triple Modular

Redundant (TMR) applications, the 3500 system should

employ two Keyphasor modules. In this configuration, the

modules work in parallel to provide both a primary and

secondary Keyphasor signal to the other modules in the rack.


Shipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service
