3500/32 Bently Nevada

3500/32 Bently Nevada  I/o Module 4 Channel Relay

Brand:Bently

Model number:3500/32

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.32kg

Shipping Port: China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

3500/32 Bently Nevada  I/o Module 4 Channel Relay



INQUIRE NOW

Products Name: 3500/32 Bently Nevada

PRODUCT DESCRIPTION

This device complies with part 15 of the

FCC Rules. Operation is subject to the

following two conditions:

 l This device may not cause harmful

interference.

 l This device must accept any

interference received, including

interference that may cause

undesired operation.

3500/32 Bently Nevada

Description:

The 4-Channel Relay Module is a full-height module that

provides four relay outputs. Any number of 4-Channel Relay

Modules can be placed in any of the slots to the right of the

Transient Data Interface Module. Each output of the 4-

Channel Relay Module can be independently programmed to

perform voting logic.

Each relay utilized on the 4-Channel Relay Module includes

Alarm Drive Logic.

Programming for the Alarm Drive Logic uses AND and OR logic,

and can use alarming inputs (Alert and Danger statuses),

Not- OK, or individual PPLs from any monitor channel or any

combination of monitor channels in the rack. You can

program this Alarm Drive to meet your application needs

using the 3500 Rack Configuration Software.

Power

Consumption

5.8 watts typical

Outputs

OK LED

Illuminated when module is

functioning properly.

TX/RX LED

 Transmit and Receive. Flashes to

indicate proper communications

between this module and other

modules within the rack.

CH ALARM LED

Illuminated to indicate that the

Relay Channel is in an alarm state.

Relays

Type

Single-pole, double-throw (SPDT)

relays

Environmental

Sealing

Epoxy-sealed

Arc

Suppressor

 250 Vrms, installed as standard

Contact Life

100,000 cycles @ 5 A, 24 Vdc or 240

Vac

Operation

 Each relay of the four channels is

switch selectable for Normally Deenergized

or Normally Energized.
