The 3300 XL probe and extension cable also reflect
improvements over previous designs. A patented TipLoc™
molding method provides a more robust bond between the
probe tip and the probe body. The probe’s cable is more
securely attached as well, incorporating a patented
CableLoc™ design that provides 330 N (75 lbf) pull
strength where the probe cable attaches to the probe tip.
3300 XL 8 mm Probes and Extension Cables can also be
ordered with an optional FluidLoc® cable option. This
option prevents oil and other liquids from leaking out of the
machine through the cable’s interior.
Description:
The 3300 XL 8 mm Proximity Transducer System consists of:
• a 3300 XL 8 mm probe
• a 3300 XL extension cable
• a 3300 XL Proximitor® Sensor1
The system provides an output voltage directly proportional to the distance between
the probe tip and the observed conductive surface. It is capable of both static
(position) and dynamic (vibration) measurements, and is primarily used for vibration
and position measurement applications on fluid-film bearing machines, as well as
Keyphasor® and speed measurement applications2.
The 3300 XL 8 mm system represents our most advanced performance in an eddy
current proximity transducer system. The standard 3300 XL 8 mm 5 metre system
is also 100% compliant with the American Petroleum Institute’s (API) 670 Standard
(4th Edition) for mechanical configuration, linear range, accuracy, and temperature
stability. All 3300 XL 8 mm Proximity Transducer Systems achieve this level of
performance while allowing complete interchangeability of probe, extension cable,
and Proximitor® Sensor without the need for individual component matching or
bench calibration.
Each component of the 3300 XL 8 mm Transducer System is backward compatible
and interchangeable3 with other non-XL 3300 series 5 and 8 mm transducer system
components4. This includes the 3300 5 mm probe, which is used when an 8 mm
probe is too large for the available mounting space5,6.
