With replacement coil at hand, remove the relay from

the panel or mounting strip. Remove the two screws that

are now accessible from the back side of the relay

baseplate. Be alert to capture the two coil springs that

are positioned between the coil and the armature carrier.

Remove the old coil and replace with a new coil. Reassemble the relay with the ends of the two coil springs

confined in their respective cavities.

Description:

Type BF (AC) and Type BFD

(DC) control relays, their latch attachments, and solid-state timers

can all be mounted on a BFMS7

mounting strip without the need for

additional hardware.

This industrial type control is

designed to be installed, operated,

and maintained by adequately

trained workmen. These instructions do not cover all details, variations, or combinations of the

equipment, its storage, delivery, Fig. 1 BF Relays on Mounting Strip

installation, check-out, safe operation, or maintenance. leads to the coil terminals. Remove the two screws that

Care must be exercised to comply with local, state, and mount the two insulated coil terminal supports and the

national regulations, as well as safety practices, for this other two screws that attach the top plate to the magnet

class of equipment.yoke. Remove the old coil and replace with a new

coil. Reassemble
