Eaton 2147A58G03 IO module

Product Overview

The EATON 2147A58G03 is a molded case circuit breaker (MCCB) accessory designed for motor protection in control panel applications. It offers adjustable magnetic overload

protection, non-interchangeable trip elements, and compatibility with E-type frame MCCBs. The 2147A58G03 is ideal for protecting motors in a wide range of applications, including

 pumps, fans, compressors, and conveyors.

Product Specifications

• Amperage rating: 100A

• Voltage rating: 480V

• Trip type: Adjustable magnetic

• Frame size: J-K

• Magnetic trip range: 300-1000A

• Maximum voltage: 600Y/347V

• Series: G

• Terminal material: Non-aluminum

• Number of poles: Three

• Certifications: UL Listed, CSA Certified

Product Advantages

• Comprehensive motor protection: The 2147A58G03 provides adjustable magnetic overload protection to safeguard motors against damage caused by excessive current draw.

• Non-interchangeable trip elements: The 2147A58G03 features non-interchangeable trip elements to prevent tampering and ensure reliable operation.

• E-type frame compatibility: The 2147A58G03 is compatible with E-type frame MCCBs, offering a wide range of installation options.

• Rugged construction: The 2147A58G03 is built with high-quality materials and components to withstand harsh environments and ensure long-lasting performance.

Considerations

• Proper sizing: It is crucial to select the 2147A58G03 with the correct amperage rating for the specific motor application to ensure adequate protection.

• Installation by a qualified electrician: The 2147A58G03 should be installed by a qualified electrician to ensure proper connection and compliance with electrical codes.

• Regular maintenance: Regular inspection and maintenance of the 2147A58G03 are essential to maintain its effectiveness and prolong its lifespan.

Product Applications

The EATON 2147A58G03 is suitable for a wide range of motor protection applications, including:

• Pumps: Protecting water, oil, and chemical pumps from overload conditions.

• Fans: Safeguarding ventilation and exhaust fans against excessive current draw.

• Compressors: Ensuring reliable operation of air compressors in various industrial settings.

• Conveyors: Protecting conveyor motors from damage caused by overload and jams.
