EATON HMCPE100R3C molded case circuit breaker

Brand: Eaton

Model number:HMCPE100R3C

Colour:new

Warranty: 12 months

Lead Time:3-day working day

Country of origin: USA Price: Please contact us

Product weight:0.21kg

Shipping Port:  China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

EATON HMCPE100R3C molded case circuit breaker


INQUIRE NOW

Products Name: EATON HMCPE100R3C molded case circuit breaker

PRODUCT DESCRIPTION

Product Overview

The EATON HMCPE100R3C is a molded case circuit breaker (MCCB) accessory designed for motor protection in control panel applications. It offers adjustable magnetic overload

protection, non-interchangeable trip elements, and compatibility with E-type frame MCCBs. The HMCPE100R3C is ideal for protecting motors in a wide range of applications, including

 pumps, fans, compressors, and conveyors.

Product Specifications

  • Amperage rating: 100A

  • Voltage rating: 480V

  • Trip type: Adjustable magnetic

  • Frame size: J-K

  • Magnetic trip range: 300-1000A

  • Maximum voltage: 600Y/347V

  • Series: G

  • Terminal material: Non-aluminum

  • Number of poles: Three

  • Certifications: UL Listed, CSA Certified

Product Advantages

  • Comprehensive motor protection: The HMCPE100R3C provides adjustable magnetic overload protection to safeguard motors against damage caused by excessive current draw.

  • Non-interchangeable trip elements: The HMCPE100R3C features non-interchangeable trip elements to prevent tampering and ensure reliable operation.

  • E-type frame compatibility: The HMCPE100R3C is compatible with E-type frame MCCBs, offering a wide range of installation options.

  • Rugged construction: The HMCPE100R3C is built with high-quality materials and components to withstand harsh environments and ensure long-lasting performance.

Considerations

  • Proper sizing: It is crucial to select the HMCPE100R3C with the correct amperage rating for the specific motor application to ensure adequate protection.

  • Installation by a qualified electrician: The HMCPE100R3C should be installed by a qualified electrician to ensure proper connection and compliance with electrical codes.

  • Regular maintenance: Regular inspection and maintenance of the HMCPE100R3C are essential to maintain its effectiveness and prolong its lifespan.

Product Applications

The EATON HMCPE100R3C is suitable for a wide range of motor protection applications, including:

  • Pumps: Protecting water, oil, and chemical pumps from overload conditions.

  • Fans: Safeguarding ventilation and exhaust fans against excessive current draw.

  • Compressors: Ensuring reliable operation of air compressors in various industrial settings.

  • Conveyors: Protecting conveyor motors from damage caused by overload and jams.
