EATON PKZ-SOL30 breaker
Share
INQUIRE NOW
Products Name: EATON PKZ-SOL30
PRODUCT DESCRIPTION
Product Description
The Eaton PKZ-SOL30 is a string circuit breaker specifically designed for photovoltaic (PV) systems.It offers a fuse-less solution for protecting PV modules against short-circuit currents.With its adjustable tripping range, the PKZ-SOL30 can be precisely tailored to match the actual short-circuit current of a specific PV string.
Key Features and Benefits
Fuse-less Protection: Eliminates the need for fuses, reducing maintenance costs and downtime.
Adjustable Tripping Range: Ensures optimal protection by allowing customization to the PV string's characteristics.
Optional Delayed Undervoltage Tripper:Facilitates remote shutdown, for instance, for fire safety purposes.
Fast Resetting: After a trip, the circuit breaker can be quickly reset, minimizing system downtime.
High Reliability: Built to withstand harsh environmental conditions and provide long-term, reliable performance.
Technical Specifications
Nominal Operating Voltage: 900 V DC
Operating Currents: 12 A, 20 A, 30 A
Permissible String Short-Circuit Currents: 1.6 to 22 A
Number of Poles: 2
Mounting: Customer-specific connection box
Applications
The PKZ-SOL30 is ideal for a wide range of PV applications, including:
Residential systems: Protecting individual PV strings in rooftop installations.
Commercial systems: Safeguarding PV arrays in commercial buildings.
Utility-scale systems: Ensuring the protection of large-scale PV plants.
Precautions and Considerations
Installation: The PKZ-SOL30 should be installed by a qualified electrician in accordance with local electrical codes and regulations.
Configuration: Proper configuration of the tripping range is essential for optimal performance. Refer to the product manual for detailed instructions.
Maintenance: Regular inspection and maintenance are recommended to ensure continued safe operation.
In essence, the Eaton PKZ-SOL30 is a robust and versatile string circuit breaker designed to enhance the safety and reliability of photovoltaic systems. Its adjustable tripping range and fuse-less design make it a valuable asset for any PV installation.
Would you like me to provide more information on a specific aspect of the PKZ-SOL30, such as installation guidelines, troubleshooting tips, or comparisons with other similar products?
Please let me know if you have any other questions.
