PLSM-C20/2-MW Eaton

Circuit breakers and fuses (EG000020) / Miniature circuit breaker (MCB) (EC000042)

Electric engineering, automation, process control engineering / Electrical installation, device / Miniature circuit breaker system (MCB) / Miniature circuit breaker (MCB)

(ecl@ss10.0.1-27-14-19-01 [AAB905014])

Built-in depth mm 70.5

Release characteristic C

Number of poles (total) 2

Number of protected poles 2

Rated current A 20

Rated voltage V 400

Rated insulation voltage Ui V 440

Rated impulse withstand voltage Uimp kV 4

Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V kA 10

Voltage type AC

Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V kA 10

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V kA 0

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V kA 0

Frequency Hz 50 - 60

Current limiting class 3

Description:

Product name Eaton Moeller series xPole - PLS6/M MCB

Part no. PLSM-C20/2-MW

EAN 4015082424060

Product Length/Depth 80 millimetre

Product height 75 millimetre

Product width 35 millimetre

Product weight 0.21 kilogram

Compliances RoHS conform

Product Tradename xPole - PLS6/M

Product Type MCB

Product Sub Type None

Delivery program

Application Switchgear for residential and commercial applications

xPole - Switchgear for residential and commercial applications

Number of poles Two-pole

Number of poles (total) 2

Number of poles (protected) 2

Tripping characteristic C

Release characteristic C

Amperage Rating 20 A

Type Miniature circuit breaker

PLSM

Technical Data - Electrical

Voltage type AC

Rated operational voltage (Ue) - max 400 V

Rated insulation voltage (Ui) 440 V

Rated impulse withstand voltage (Uimp) 4 kV

Frequency rating - min 50 Hz

Frequency rating - max 60 Hz

Rated switching capacity (IEC/EN 60898-1) 10 kA

Rated short-circuit breaking capacity (EN 60898) at 230 V 10 kA

Rated short-circuit breaking capacity (EN 60898) at 400 V 10 kA

Rated short-circuit breaking capacity (IEC 60947-2) at 230 V 0 kA

Rated short-circuit breaking capacity (IEC 60947-2) at 400 V 0 kA

Overvoltage category III

Pollution degree 2

Technical Data - Mechanical

Width in number of modular spacings 2

Built-in depth 70.5 mm

Degree of protection IP20

Connectable conductor cross section (solid-core) - min 1 mm²

Connectable conductor cross section (solid-core) - max 25 mm²

Connectable conductor cross section (multi-wired) - min 1 mm²

Connectable conductor cross section (multi-wired) - max 25 mm²

Design verification as per IEC/EN 61439 - technical data

Rated operational current for specified heat dissipation (In) 20 A

Heat dissipation per pole, current-dependent 0 W
