The FBM233 Redundant Field Device System Integrator (FDSI) module provides an Ethernet interface
between single or dual-ported field I/O devices and the Foxboro Evo
system.
Description:
FEATURES
Key features of the FBM233 are:
4 Redundant 10 Mbps or 100 Mbps Ethernet
network transmission rate to/from field devices
4 Communicates with up to 64 field devices
4 I/O software driver is downloadable from a library
of available protocols
4 Up to 2000 DCI block connections
4 Integrates field device data into a Foxboro Evo
control database using Ethernet connectivity
4 Field mounted
4 Class G3 (harsh) environments.
I/O DRIVERS
This FBM is a generic Ethernet hardware module in
which different software drivers can be loaded. These
drivers configure the FBM to recognize a particular
protocol used by the device. Several of these
software drivers are a standard product offerings.
Other custom drivers can be developed to meet
specific needs. These drivers are dynamically
downloaded to the FBM233 with software code
specifically designed to interface with the third party
device’s protocol.
The configuration procedures and the software
requirements for each driver are unique to the
device(s) being integrated into the system.
ETHERNET LINK SETUP
Data communication between the FBM233 and field
devices are through the RJ-45 connector located on
the front of the FBM233 module. The RJ-45
connector of the FBM233 can be connected through
hubs, or through Ethernet switches to the field
devices (refer to “ETHERNET SWITCHES FOR USE
WITH FBM233” on page 7). The FBM233 is
connected to Ethernet switches or hubs in order to
communicate with one external device or up to 64
external devices.
