Product Description
The FOXBORO FBM242 is a discrete output interface module that is part of the I/A Series DIN rail mounted FBM subsystem field wiring termination family. It offers 16 discrete output channels, each capable of driving
loads up to 2A at 60V DC. These outputs are externally sourced, meaning they require an external power supply to energize the field circuits.
Key Features and Benefits
16 Discrete Outputs: Provides ample output channels for various applications.
External Sourcing: Offers flexibility in power supply options.
Galvanic Isolation: Ensures electrical isolation between channels and the module.
Rugged Design: Suitable for harsh industrial environments.
Configurable Options: Allows for customization to meet specific application requirements.
Compact Design: Saves space in control panels.
Technical Specifications
Number of Outputs: 16
Output Voltage: 15 to 60V DC, 120V AC/125V DC, 240V AC
Output Current: Up to 2A
Isolation: Galvanic isolation between channels and module
Operating Temperature: -20 to +70°C
Mounting: DIN rail
Certifications: CE, RoHS
Precautions
External Power Supply: Ensure a suitable external power supply is used.
Wiring: Proper wiring is essential to prevent damage and ensure correct operation.
Environment: Avoid exposing the module to excessive heat, humidity, or vibration.
Maintenance: Regular inspection and maintenance are recommended.
Applications
The FBM242 is widely used in various industrial applications, including:
Process Control: Controlling valves, motors, and other actuators.
Machine Automation: Driving relays, solenoids, and other discrete devices.
Safety Systems: Implementing safety interlocks and emergency stop functions.
Additional Information
Termination Assembly: The FBM242 requires a termination assembly for connecting to external devices.
Configuration: The module can be configured using the I/A Series configuration software.
Compatibility: The FBM242 is compatible with other I/A Series products.
Would you like to know more about a specific aspect of the FBM242, such as its configuration options or compatibility with other devices?
Please let me know if you have any other questions.
Note: This information is based on publicly available data and may not be entirely comprehensive. Always refer to the official product documentation for the most accurate and up-to-date information.
