Product Description
The GE Multilin 469-P5-HI-A20-E is a motor management relay designed to protect, control, and monitor medium and large motors. It is part of the Multilin 469 series, which is known for
its reliability, performance, and versatility.
The 469-P5-HI-A20-E offers a wide range of features, including:
Comprehensive motor protection: The relay provides overcurrent, overvoltage, undervoltage, phase reversal, and other protection functions.
Advanced metering: The relay measures motor current, voltage, power, energy, and other key parameters.
Intelligent communication: The relay supports a variety of communication protocols, including Modbus RTU, DNP3, and IEC 61850.
User-friendly interface: The relay has a large LCD display and a menu-driven interface that is easy to use.
Product Specifications
Rated voltage: 240 to 690 VAC
Rated current: 5 to 2000 A
Accuracy: ±1% of full scale
Communication protocols: Modbus RTU, DNP3, IEC 61850
Operating temperature: -40 to 70°C
Storage temperature: -55 to 85°C
Product Advantages
Comprehensive protection: The 469-P5-HI-A20-E provides a wide range of protection functions to help prevent motor damage and downtime.
Advanced metering: The relay's advanced metering capabilities provide valuable insights into motor performance, which can help to improve efficiency and reduce maintenance costs.
Intelligent communication: The relay's support for a variety of communication protocols makes it easy to integrate into existing control systems.
User-friendly interface: The relay's large LCD display and menu-driven interface make it easy to use and configure.
Considerations
The 469-P5-HI-A20-E is a complex device that should be installed and configured by qualified personnel.
The relay should be properly grounded to ensure safety.
The relay should be installed in a location that is free from excessive dust, moisture, and vibration.
Product Applications
The 469-P5-HI-A20-E is a versatile relay that can be used in a wide variety of applications, including:
Pumps
Fans
Compressors
Conveyor belts
Machine tools
Hoists
Cranes
Conclusion
The GE Multilin 469-P5-HI-A20-E is a powerful and versatile motor management relay that can provide comprehensive protection, advanced metering, and intelligent communication
for medium and large motors. It is a valuable asset for any industrial application.
