Brand：GE
Model number：531X303MCPBBG1
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.27kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
531X303MCPBBG1 GE Controller module Brand new
Battery installation When installing a new battery, when there currently is no battery
installed, the battery must be installed while the CPU has power.
Failing to follow this procedure could result in the CPU not powering
up.
If a battery is installed while power is off (and there was no battery
previously installed), and the CPU fails to power up, simply remove the
battery, power cycle the CPU and then install the battery.
CPU may not detect low-battery condition PACSystems CPUs may not detect a low-battery condition early
enough to provide a meaningful warning to the user to replace the
battery. A battery with very low capacity may still have a terminal
voltage high enough to report that it is a good battery. In this case,
when the battery starts supplying the memory power (battery backup),
the battery voltage would quickly drop to unacceptable levels, with little
warning to the user before failure.
To insure against data loss, users should replace batteries in
accordance with the guidelines provided in the CPU Reference
Manual, GFK-2222. Additionally, users could save logic and hardware
configuration to flash.
Ethernet disconnect during word for word
change
If the Ethernet connection is broken during a word-for-word change,
the programmer may not allow a subsequent word-for-word change
after reconnecting due to the fact that it thinks another programmer is
currently attached. If this occurs, you should go offline and then back
online again.
VME modules operating as VME masters
are not supported
The RX7i does not support VME modules operating as bus masters.
Store of hardware configuration with
multiple GBCs
Storing a hardware configuration containing two or more Series 90-70
GBCs twice may cause one GBC to fail configuration. Clearing the
hardware configuration between stores will prevent this fault from
being generated. (Note: This issue does not affect Series
90-30 GBCs.)
Simultaneous Clears, Loads and Stores
not supported
Currently, the RX7i does not support multiple programmers changing
CPU contents at the same time. The programming software may
generate an error during the operation
