Brand：GE
Model number：A02B-0166-B531
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.27kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
A02B-0166-B531 GE Power module Brand new
SRTP connections remain open after IP
address changed
The Ethernet Interface does not terminate all open SRTP connections
before changing its IP address. Once the local IP address has changed,
any existing open TCP connections are unable to normally terminate. This
can leave SRTP connections open until their underlying TCP connections
time out. If quicker recovery of the SRTP connection is needed, modify
the “wkal_idle” Advanced User Parameter to reduce the TCP keep alive
timer down to the desired maximum time for holding open the broken
connection. Refer to TCP/IP Ethernet Communications for PACSystems,
GFK-2224, for details.
CPU time used for produced EGD
Timestamps
Changing the Ethernet interface time via the CHTIME command does not
affect the timestamp value within EGD exchanges produced from this
Ethernet interface. The EGD timestamp value reflects the current CPU
time. In Series 90-70 products and the Series 90-30 CPU364, EGD
timestamps are taken from the Ethernet interface and do reflect CHTIME
modifications.
ENIU stale data during run mode store
of EGD
In a large PPS system running 20 ENIUs, when a Run-mode Store is
performed that deletes the EGD exchanges for 10 of the ENIUs, the other
ENIUs will see the status on their exchanges indicate consumption
timeouts during the RMS. At the completion of the RMS, the exchanges
operate normally.
Internet Explorer 8 may require setting
changes when using Web pages on
RX7i
It may be required to disable the pop-up blocker when using Internet
Explorer 8 with the Web pages supplied with the RX7i Ethernet firmware.
To disable the pop-up blocker, in the Internet Explorer toolbar, select
Tools->Pop-up Blocker->Turn Off Pop-up Blocker
Note: If you have the Google toolbar installed, the Google pop-up
blocker may also have to be disabled.
It may also be required to disable configuration scripts when using
Internet Explorer 8. In the Toolbar select Internet Options. In the Internet
Options dialog box click the “Connections” tab, click the “LAN settings”
button, and make sure the box beside “Automatically detect settings” has
a check in it. If it does not, click the box next to “Automatically detect
settings” to enable this setting.
Discrete Input
Modules(1) IC200MDL140 Input 120 VAC (1 Group of 8) 8
Points IC200MDL631 Input 125 VDC Pos/Neg Logic
Isolated 8 Points
IC200MDL141 Input 240 VAC (1 Group of 8) 8
Points IC200MDL632 Input 125 VDC Pos/Neg Logic
Isolated 16 Points
IC200MDL143 Input 120 VAC Isolated 8 Points IC200MDL635 Input 48 VDC Pos/Neg Logic (2
Groups of 8) 16 Points
IC200MDL144 Input 240 VAC Isolated 4 Points IC200MDL636 Input 48 VDC Pos/Neg Logic (4
Groups of 8) 32 Points
IC200MDL240 Input 120 VAC (2 Groups of 8) 16
Points IC200MDL640 Input 24 VDC Pos/Neg Logic (2
Groups of 8) 16 Points
IC200MDL241 Input 240 VAC (2 Groups of 8) 16
Points IC200MDL643 Input 5/12 VDC Pos/Neg Logic (2
Groups of 8) 16 Points
IC200MDL243 Input 120 VAC Isolated 16 Points IC200MDL644 Input 5/12 VDC Pos/Neg Logic (4
Groups of 8) 32 Points
IC200MDL244 Input 240 VAC Isolated 8 Points IC200MDL650 Input 24 VDC Pos/Neg Logic (4
Groups of 8) 32 Points
