Brand：GE
Model number：A03B-0819-C056
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.27kg
Shipping Port: China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
A03B-0819-C056 GE Controller module Brand new
• The embedded Ethernet interface is supported by a dedicated microprocessor core. This
dedicated processing capability permits the CPU to support these two LANs with:
o up to 48 simultaneous SRTP Server connections;
o up to 16 simultaneous Modbus/TCP Server connections;
o 32 Clients are permitted; each may be SRTP or Modbus/TCP.
o OPC UA Server with support for up to 5 concurrent sessions with up to 10
concurrent variable subscriptions and up to 12,500 variables;
o up to 255 simultaneous Class 1 Ethernet Global Data (EGD) exchanges;
o two independent Redundant IP addresses, one for each of the embedded
Ethernet LANs.
• Achilles Level 2 Communications Certification1.
• Optional Energy Pack, IC695ACC402, allows CPE330 to instantly save user memory to
non-volatile storage in the event of loss of power.
• Ability to transfer user programs and/or data to and from USB 2.0 A type Removable
Data Storage Devices (RDSDs).
• HART Pass Through allows the CPE330 to communicate HART asset management data
between HART-capable I/O modules and PC-based asset management tools. (Requires
additional HART-compatible products.)
• User may program in Ladder Diagram, Structured Text, Function Block Diagram, or C.
• Contains 64Mbytes of configurable data and program memory.
• Supports auto-located Symbolic Variables that can use any amount of user memory.
• Reference table sizes include 32k bits for discrete %I and %Q and up to 32k words
each for analog %AI and %AQ. Bulk memory (%W) also supported for data
exchanges.
• Supports up to 512 program blocks. Maximum size for a block is 128KB.
• For supported I/O, Communications, Motion, and Intelligent modules, refer to the
PACSystems RX3i System Manual, GFK-2314.
Discrete Input
Modules(1) IC200MDL140 Input 120 VAC (1 Group of 8) 8
Points IC200MDL631 Input 125 VDC Pos/Neg Logic
Isolated 8 Points
IC200MDL141 Input 240 VAC (1 Group of 8) 8
Points IC200MDL632 Input 125 VDC Pos/Neg Logic
Isolated 16 Points
IC200MDL143 Input 120 VAC Isolated 8 Points IC200MDL635 Input 48 VDC Pos/Neg Logic (2
Groups of 8) 16 Points
IC200MDL144 Input 240 VAC Isolated 4 Points IC200MDL636 Input 48 VDC Pos/Neg Logic (4
Groups of 8) 32 Points
IC200MDL240 Input 120 VAC (2 Groups of 8) 16
Points IC200MDL640 Input 24 VDC Pos/Neg Logic (2
Groups of 8) 16 Points
IC200MDL241 Input 240 VAC (2 Groups of 8) 16
Points IC200MDL643 Input 5/12 VDC Pos/Neg Logic (2
Groups of 8) 16 Points
IC200MDL243 Input 120 VAC Isolated 16 Points IC200MDL644 Input 5/12 VDC Pos/Neg Logic (4
Groups of 8) 32 Points
IC200MDL244 Input 240 VAC Isolated 8 Points IC200MDL650 Input 24 VDC Pos/Neg Logic (4
Groups of 8) 32 Points
