• Completely software-configurable, no module jumpers to set
• On-board error-checking
• Open-circuit detection for all voltage and 4-20mA inputs
• Configurable scaling and offsets per channel
• High alarm, low alarm, high-high alarm, low-low alarm detection and reporting
selectable per channel
• Module fault reporting
• Supports diagnostic point fault contacts in the logic program
• Flash memory for future upgrades
• Positive and negative Rate of Change Alarms
• Configurable interrupts for channel alarms and faults
• Terminal Block insertion or removal detection
• Hot-swappable— module may be inserted into or removed from a powered backplane
Description:
Isolated Analog Voltage/Current Input module IC695ALG106 provides 6 isolated input
channels.
Isolated Analog Voltage/Current Input module IC695ALG112, shown at right, provides
12 input channels.
Analog input channels can be configured for these ranges:
• Current: 0 to 20mA, 4 to 20mA, +/- 20mA
• Voltage: +/- 10V, 0 to 10V, +/- 5V, 0 to 5V, 1 to 5V
These modules must be installed in an RX3i Universal Backplane. The modules require
the use of one front-mounted terminal block (ordered separately). Terminal blocks are
available in the following different styles:
• Box-style (IC694TBB032),
• Extended Box-style (IC694TBB132),
• Spring-style (IC694TBS032), and
• Extended Spring-style (IC694TBS132).
Extended terminal blocks provide the extra shroud depth needed for shielded wiring.
See GFK-2314, PACSystems RX3i System Manual, for more information about terminal
blocks.
Note: Terminal blocks for this module must be ordered separately.
