Genius Analog Mixed blocks provide 4 channels of inputs and 2 channels of outputs.
The channels can be configured for current or voltage with powerful diagnostics.
IC660BBA020 IC660BBA100 IC660BBA024 IC660BBA104
Product Name
Genius Analog I/O Block,
Voltage/Current,
4 Inputs/ 2 Outputs,
24/48 VDC Powered
Genius Analog I/O Block,
Voltage/Current,
4 Inputs/ 2 Outputs,
115 VAC Powered
Genius Analog I/O Block,
Current-source,
4 Inputs/ 2 Outputs,
24/48 VDC Powered
Genius Analog I/O Block,
Current-source,
4 Inputs/ 2 Outputs,
115 VAC/ 125 VDC Powered
Lifecycle Status Mature Mature Mature Mature
Network Support Genius Bus Genius Bus Genius Bus Genius Bus
Number of Points 4 In / 2 Out 4 In / 2 Out 4 In / 2 Out 4 In / 2 Out
Points Per Common One group of 4 Inputs and
one group of 2 Outputs
One group of 4 Inputs and
one group of 2 Outputs
One group of 4 Inputs and
one group of 2 Outputs
One group of 4 Inputs and
one group of 2 Outputs
Input Range 0–10 VDC, 10 VDC, 5 VDC,
0–5 VDC, 4–20 mA (or 1–5 VDC)
0–10 VDC, 10 VDC, 5 VDC,
0–5 VDC, 4–20 mA (or 1–5 VDC)
4 mA to 20 mA 4 mA to 20 mA
Output Range 0–10 VDC, 10 VDC, 5 VDC,
0–5 VDC, 4–20 mA (or 1–5 VDC)
0–10 VDC, 10 VDC, 5 VDC,
0–5 VDC, 4–20 mA (or 1–5 VDC)
4 mA to 20 mA 4 mA to 20 mA
Operating Voltage 18-56 VDC 98-132 VAC 18-56 VDC 93-132 VAC / 105-145 VDC
Resolution 12 bit + sign 12 bit + sign Input: 1 micro Amp
Output: 6 micro Amp
Output: 6 mA
Update Rate
Once every 4mS Once every 4mS Input: 16.6mS to 400mS
(user selectable)
Output: 6mS to 8mS typical
Input: 16.6mS to 400mS
(user selectable)
Output: 6mS to 8mS typical
Accuracy
Typical: 0.2% of full scale;
Maximum: 0.5% of full scale:
within 50mV on the 10 volt
range, 25mV on the 5 volt
range, and 100mA on the 4
to 20 mA range.
Typical: 0.2% of full scale;
Maximum: 0.5% of full scale:
within 50mV on the 10 volt
range, 25mV on the 5 volt
range, and 100mA on the 4
to 20 mA range.
Input: 0.1% of full scale
reading
Output: 0.15% of full
scale reading
Input: 0.1% of full scale
reading
Output: 0.15% of full
scale reading
Input Filter Response none, 8, 16, 32, 64, 128, 256,
512, 1024mS
none, 8, 16, 32, 64, 128, 256,
512, 1024mS
16.6mS to 400mS
(user selectable)
16.6mS to 400mS
(user selectable)
Diagnostics
Input: Underrange, Overrange,
High Alarm, Low Alarm,
Open Wire Output:
Underrange, Overrange
Input: Underrange, Overrange,
High Alarm, Low Alarm,
Open Wire Output:
Underrange, Overrange
Input: Underrange, Overrange,
High Alarm, Low Alarm,
Open Wire Output:
Underrange, Overrange,
Feedback error
Input: Underrange, Overrange,
High Alarm, Low Alarm,
Open Wire, Output:
Underrange, Overrange,
Feedback error
Dimensions (W x H x D)
8.83” (22.44cm) x
3.50” (8.89cm) x
3.94” (10.00cm)
8.83” (22.44cm) x
3.50” (8.89cm) x
3.94” (10.00cm)
8.83” (22.44cm) x
3.50” (8.89cm) x
3.94” (10.00cm)
8.83” (22.44cm) x
3.50” (8.89cm) x
3.94” (10.00cm)
