IC660EBD101F GE FANUC programmable controller module

INQUIRE NOW

Products Name: IC660EBD101F GE FANUC programmable controller module

PRODUCT DESCRIPTION

Brand：GE

Model number：IC660EBD101F

Colour：new

Warranty: 12 months

Lead Time：3-day working day

Country of origin: USA Price: Please contact us

Product weight：0.44kg

Shipping Port: Xiamen, China

Payment: Bank of Chicago, Bank of Singapore

Express cooperation: fedex, DHL, UPS and your express account

Service: Professional Sales provides 24 hours /7 days online service

Description:

Features

Block features include:

Selectable input Filter Time from 10ms to 100ms.

Output feedback for monitoring.

Output powerup defaults.

Outputs hold last state or default.

Pulse Testing for outputs

Bus Switching Module control.

Control power for the block is tapped off the input/output device

voltages wired to the terminals. No separate block power supply is

needed.

Each circuit has electronic fusing that shuts down the circuit in 5ms

if output current exceeds 30 Amps with the output turned on, or 20

Amps after 2 cycles. The circuit is easily restored by command from

a Hand-held Monitor or the CPU.

Block diagnostics include:

Overtemperature

Failed Switch

Open Wire for tristate inputs

Overload Detection and Shutdown

No-load Detection

Fault reporting can be enabled or disabled circuit by circuit.

This block is fully compatible with Hand-held Monitor model

IC66*HHM501. It may be used with IC66*HHM500; however,

HHM501 is required to change the baud rate or to configure the

block for redundancy.

If the block will be used on a bus controlled by an IC550 series PLC,

or a host computer equipped with a bus interface module, and the

block will be configured as an inputs-only block, it may be necessary

to upgrade the IC550 bus controller or computer bus interface

module as detailed in the Discrete and Analog Blocks User’s

Manual.

Block IC66*BBD101 is designed to control small loads without the

addition of parallel load resistance. It is also suitable for installations

where a Class 1 Division 2 rating is required for Factory Mutual.

This block is backward compatible with blocks IC66*CBD100 and

BBD100, and may be used to replace them. Electronics Assembly

IC66*EBD101 replaces IC66*ELD100 and EBD100. Terminal

Assemblies IC66*TSD100E and later are not compatible with earlier

versions of the Electronics Assembly. If the Terminal Assembly will

be used to replace Terminal Assembly IC66*TSD100D or earlier, the

Electronics Assembly must be either replaced with version

IC66*EBD101F or later, or upgraded.
