Brand：GE
Model number：IC660TSS100E
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.55kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
This flexibility allows these blocks to be used with a wide variety of
analog input and output devices. The block’s internal power supply
drives current mode output loads up to 300 Ohms each. For loads
up to 2K Ohms, an external 24 or 48 VDC power supply can be
used.
Configurable block features include:
Independent scaling for each input and output.
Fault reports to the host can be enabled or disabled for each
input and output.
Selectable Input Filter Time up to 1024ms.
Each input can operate in normal analog input mode, or report
only its alarm status.
Low and high alarm limits for each input, in either normal input
mode or alarm input mode.
Powerup default values for each output.
Each output can be configured to hold last state or default if
CPU communications are lost.
Input Low Alarm and High Alarm detection.
Open Wire detection on current mode inputs.
Input Underrange or Overrange.
Output Underrange or Overrange.
These blocks are backward-compatible with earlier versions, and
may be used to replace them.
Any Hand-held Monitor (IC66*HHM500 or HHM501) can be used
with these blocks. However, Hand-held Monitor model
IC66*HHM501 is required to change baud rate configuration, or to
configure redundancy features. Note that older HHM model
IC66*HHM501 version 3.5 may incorrectly display the message
WIRING ERROR during normal operation. Upgrading the HHM to a
later version corrects this problem.
For an IC697 series PLC, the CPU and programming software must
be version 2.0 or later. The bus controller must be IC697BEM731C
or later.
For an IC600 series PLC, the CPU must be rev. 105 or later. For an
IC600 series “Plus” PLC rev. 110 or later is required. The
programming software must be rel. 4.02 or later.
For an IC550 series PLC, the CPU must be rev. 3.0 or later. The
programming software must be rel. 2.01 or later.
Current-source analog blocks are preferred for current-loop
applications. Please request information about:
115VAC/125VDC Current-source Analog 4 Input/2 Output Block
(IC66*BBA104)
24/48 VDC Current-source Analog 4 Input/2 Output Block (IC66*BBA024)
115VAC/125VDC Current-source Analog Output Block (IC66*BBA105)
115VAC/125VDC Current-source Analog Input Block (IC66*BBA106)
24/48 VDC Current-source Analog Block Input Block (IC66*BBA026)
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
