Brand：GE
Model number：IC697PWR711
Colour：new
Warranty: 12 months
Lead Time：3-day working day
Country of origin: USA Price: Please contact us
Product weight：0.22kg
Shipping Port: Xiamen, China
Payment: Bank of Chicago, Bank of Singapore
Express cooperation: fedex, DHL, UPS and your express account
Service: Professional Sales provides 24 hours /7 days online service
Description:
Terminal Block Assembly
1. Press the terminal block assembly
straight toward the module until it
is partially seated.
2. Open the door on the front of the
terminal block and push the latch
(see below) up very firmly until it
reaches the top of the slot and
clicks into place.
3. Check to be sure the terminal
block is fully seated.
Removing a High-density Terminal
Block from the Module
1. Open the terminal block door.
2. Push the latch down as shown at left very
firmly until the terminal block is released.
3. Pull the terminal block away from the
module until the contacts have separated.
Removing a Terminal Block from its
Cover
To remove a Terminal Block from its cover:
1. Grasp the sides of the Terminal Block cover.
2. Pull down on the bottom of the Terminal Block.
Extended High-Density Terminal Blocks IC694TBB132 and IC694TBS132 are functionallyidentical to High-Density Terminal Blocks IC694TBB032 and IC694TBS032. The Extended
High-Density Terminal Blocks have an outer cover that is approximately ½-inch (13mm) deeper,
to accommodate wires with thicker insulation, such as that typically used with AC I/O modules.
13mm
(0.5 inch)
The diagram below compares the
space for wiring on a High-Density
Terminal Block (left) and an
Extended High-Density Terminal
Block (right), seen from the bottom
of the module.
