SD17060B and SD17060B-03 digital inputs accept 5Vdc to 24Vdc without the need of an external current limiting resistor
SD17060B-25 digital inputs will work with 24Vdc only
Common features of the three drivers include:
Inputs that accept 5Vdc to 24Vdc without the need of an external current limiting resistor
Anti-Resonance Circuitry
Back-EMF Protection Circuity
Programmable Idle Current Reduction
Programmable Current Loop Gain
Programmable Pulse Train Input (Step/Direction or CW/CCW)
Programmable Active State for the Disable Input
Description:
If your year of manufacture is 2009 or later, (digits 3 and 4 are “09” or greater), then this manual
applies.
If your month and year of manufacture is December of 2008, (digits 1 through 4 are “1208”), and the
sequential number is “0135” or greater, then this manual applies.
If your month and year of manufacture is December of 2008, (digits 1 through 4 are “1208”), and the
sequential number is less than “0135” then most of the information in this manual applies. The only
difference is that these older SD17060B drivers require external resistors for input signals greater than
5Vdc. Refer to Appendix A on page 18 for additional information.
If your month and year of manufacture is November of 2008 or earlier, (digits 1 through 4 are “1108”
or less), then most of the information in this manual applies. The only difference is that these older
SD17060B drivers require external resistors for input signals greater than 5Vdc. Refer to Appendix A
on page 18 for additional information.
For SD17060B-03 Drives...
The “-03” option was added in February of 2010. This manual applies to all SD17060B-03 units.
For SD17060B-25 Drives...
SD17060B-25 drivers have different resolution settings than the SD17060B and SD17060B-03. In
addition to this change, the SD17060B-25 will only accept 24Vdc input signals. The SD17060B-25
cannot be used in systems that have 5Vdc differential or 12Vdc single ended signals.
