KONGSBERG RMP400

Loop voltage: 24 VDC +/- 20%

Input loop current: maximum 4 mA at 24 VDC loop voltage

Channel “off” current: <0.5 mA

Channel “on” current: >3 mA

Maximum input voltage: loop voltage

Maximum input

signal frequency: 10 ms pulse

Connectors: screw terminals, 2.5 mm2

• Up to 32 individually dened digital inputs or

 outputs

• Dual Serial Process Bus (SPBus) interfaces to allow

optional redundancy

• Each SPBus interface ensures electrical isolation

from the control system

• Easy installation and replacement:

 - DIN standard rail-mounting

 - plug-in connections

• Status LED for normal operation or error condition

• Loop-check and debugging from operator station

and local data terminal

• Short-circuit proof loop current driver

• Fail-safe activation of outputs upon loss of communication

•

Built-in test for self diagnostics and fault

 identication

• SIL 1 compliant

• Line Fault Detection (LFD)

• Earth Fault Detection (EFD)

• Dual watch-dogs

The Kongsberg Maritime Remote Input and Output

system (RIO400) uses a Serial Process Bus (SPBus)

between a controller computer in the process network

and the input and output (I/O) signals to remote

devices such as valves, relays and temperature sensors.

The

RDIO400 is an interface module between the

SPBus and digital inputs or outputs to and from eld

devices.

The RIO400 system provides a cost-effective solution

for connecting any number of inputs and outputs to a

Kongsberg Maritime automation system, independent

of the distance between the remote equipment and the

controller computer.
